Huis> Product List> Scheermeerharteldraad> Prikkeldraad> Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape
Airport Security Coils Concertina Razor Cephbed Tape

Airport Security Coils Concertina Razor Cephbed Tape

Ontvang de meest recente Prijs
betaling Type:L/C,T/T,D/P
Incoterm:FOB,CFR,CIF,EXW
Min. orde:1 Piece/Pieces
vervoer:Ocean,Land,Air
Haven:TIANJIN
Productkenmerken

Barbed Distance4"

Barb Length15mm

Coil Outside Diameter500mm

ColorGreen

Blade Thickness0.5+/-0.5mm

Barb Width15+/-1mm

Hole ShapeRound

FeatureRot Proof, Waterproof

certificaatIso9001

Transport PackageBulk, Plastic Weaving Bags

SpecificationBTO-28

TrademarkRUILI

OriginHebei, China

GS-code7313000

productiecapaciteit50 Tons /Day

MaterialGalvanized Steel Wire

Twist MethodDouble Twist

ToepassingProtecting Mesh, Fence Mesh

FinishHot Dipped Galvanized

Razor Barbed TypeCross Razor

Wire Gauge12x14 BWG

Verpakking & Levering
Verkoopeenheden : Piece/Pieces

The file is encrypted. Please fill in the following information to continue accessing it

[Militaire stijl] Hoge koolstof Gegalvaniseerde meervoudige grensbarrière Concertina Razor Fence1
Beschrijving
Producten detail
Specificatie
1, Materiaal : warm -dip gegalvaniseerde plaat en draad of roestvrijstalen plaat en draad (ALSI 430 en ALSI 304)
2, Diameter van de buitendiameter : 450 mm, 500 mm, 600 mm, 700 mm, 800 mm, 900 mm, 960 mm, 980 mm
3, Aantal loops : 33, 56
4, clips : 3, 5
5, verpakking: binnenbestendig papier, buitenweventas of doos met doos
Alle specificatie en verpakking kunnen worden ontworpen volgens de behoefte van de klanten.
Model Thickness Wire dia Barb Length Barbed Width
Barb Spacing

BTO-10 0.5+/-0.05 mm 2.5+/-0.1mm 10+/-1mm 13+/-1mm 26+/-1mm
BTO-12 0.5+/-0.05 mm 2.5+/-0.1mm 12+/-1mm 15+/-1mm 26+/-1mm
BTO-18 0.5+/-0.05 mm 2.5+/-0.1mm 18+/-1mm 15+/-1mm 38+/-1mm
BTO-22 0.5+/-0.05 mm 2.5+/-0.1mm 22+/-1mm 15+/-1mm 38+/-1mm
BTO-28 0.5+/-0.05 mm 2.5+/-0.1mm 28+/-1mm 15+/-1mm 53+/-1mm
BTO-30 0.5+/-0.05 mm 2.5+/-0.1mm 30+/-1mm 21+/-1mm 54+/-1mm
CBT-60 0.6+/-0.05 mm 2.5+/-0.1mm 60+/-2mm 32+/-1mm 102+/-1mm
CBT-65 0.3+/-0.05 mm 2.5+/-0.1mm 65+/-2mm 21+/-1mm 102+/-1mm
Outside diameter No. of loops The utmost effective length Type Notes
450 mm 33 7 - 8 M CBT 60.65 Single coil
500 mm 56 12 - 13 M CBT 60.65 Single coil
700 mm 56 13 - 14 M CBT 60.65 Single coil
960 mm 56 14 - 15 M CBT 60.65 Single coil
450 mm 56 8 - 9 M (3 CLIPS) BTO - 10.12.18.22.28.30 Cross type
500 mm 56 9 - 10 M (3 CLIPS) BTO - 10.12.18.22.28.30 Cross type
600 mm 56 10 - 11 M (3 CLIPS) BTO - 10.12.18.22.28.30 Cross type
600 mm 56 8 - 10 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
700 mm 56 10 - 12 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
800 mm 56 11 - 13 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
900 mm 56 12 - 14 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
960 mm 56 13 - 15 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
980 mm 56 14 - 16 M (5 CLIPS) BTO - 10.12.18.22.28.30 Cross type
